Switchcraft 35HDBAUS 3.5 Stereo Phone Plug Cryo Treated

Switchcraft 35HDBAUS 3.5 Stereo Phone Plug Cryo Treated
Switchcraft 35HDBAUS 3.5 Stereo Phone Plug, 1 pc, Deep Cryo Treated
Our PriceCAD $11.95
CodeDCT SC 35HDBAUS
Weight Kg.012
In Stock
No Reviews
Save wishlist

Switchcraft 35HDBAUS

3.5 mm Heavy Duty Stereo Plug; Black Handle, Gold Plug.

Features:

  • One piece tip rod with flat for easy solderability.
  • Compliments current line of 3.5 mm jacks.
  • Insert molded plug finger.
  • Heavy Duty cable clamp provides better strain relief for larger cables
  • Longer cable clamp for easier plug assembly and more room for solder connections
  • Knurl on the back of handle provides ergonomic gripping surface to tighten plug
  • Tubular insulator included to prevent solder joints from contacting handle
  • Longer handle for improved gripping surface and easy plug withdrawal from jack
  • Large solder terminal for easy solderability

Specificatons:

  • Contact Resistance:<0.020 ohms
  • Dielectric Withstand Voltage: 250 VAC (min.)
  • Insulation Resistance @ 500 VDC: 2,000 megohms (min.)
  • Working Voltage: 250 VAC, 140 VDC
  • Current Carry @ Working Voltage: 4 AMPS
  • Insert/Withdrawal Force: Typical 2.5/2 pounds
  • Temperature Range: 0° to 66° Centigrade (operating) Passed MIL-STD-202F Method 107G (Thermal Shock), and Method 201 (Vibration)
  • Life: 5000 cycles
  • Maximum Cable Size: 4.5mm dia

This part has been Deep Cryo Treated by Take Five Audio, click HERE for full details on our process.
