ViaBlue™ T6s phono 1/4" mono plugs have contact pins made of bronze
which are 24 carat gold-plated. The shells are made of aluminum. Cables
up to 9.5 mm diameters can be installed. All connectors of the T6s
series are supplied including two diameter reducers.
For assembly the stripped cable ends are soldered at the
contact parts of the T6s plugs. The contact part can be removed
completely from the plug's shell. The M4 screw serves as strain relief.
The shell for all plugs (exception: XLR plugs) of the ViaBlue™ T6s
series are identical. Only the contact parts change.
Each T6s plug contains two diameter reducers which serve
for a firm strain relief and concentric alignment of the cables. The small
diameter reducer has an outer diameter of 7.5 mm and an inner
diameter of 4.5 mm. Thus cables with an outer diameter of 3 mm up to
4.5 mm can be fixed firmly. The big diameter reducer has an outer
diameter of 9.5 mm and an inner diameter of 7.5 mm allowing cables with an
outer diameter from 5 mm to 7.5 mm can be fixed firmly. Without using
any reducer cables with diameters from 7.5 mm to 9.5 mm can
VIABLUE™ T6s SERIES. THE 6TH SENSETechnical specifications:
- Max outer diameter: 13.5 mm
- Contact: 6.3mm (1/4") Mono
- Finishing: 24 Karat Gold plated
- Total length: 61.2mm
- Max cable input: for cables with Ø 3 - 9.5 mm
- Marking: black
- Screws: 1.5 mm Hexagon
This part has been Deep Cryo Treated by Take Five Audio, click HERE for full details on our process.
