Neutrik Tiny XLR Chassis Mount Male Cryo Treated

Neutrik Tiny XLR Chassis Mount Male Cryo Treated
Neutrik Chassis Mount Tiny XLR Male, Deep Cryo treated, 1 pc
Our PriceCAD $2.95
CodeDCT NEU RT3MP
Weight Kg.044
In Stock1
No Reviews
Save wishlist
Add to comparison | Compare Products

3-pole TINY chassis connector, Nickel metal housing, gold plated contacts.

Max. panel thickness: 6 mm
  • Gender male
  • Contact resistance < 5 mOhm
  • Dielectric strength > 0.5 kVdc
  • Insulation resistance > 1 GOhm
  • Rated current per contact < 5 A
  • Lifetime > 1000 mating cycles
  • Wiring Solder contacts
  • Contact plating Au
  • Contacts Brass
  • Insert PA 6.6 30 % GF
  • Shell Zinc diecast
  • Shell plating Nickel
  • Solderability Complies with IEC 68-2-20
  • Temperature range -30° C to +80° C

This part has been Deep Cryo Treated by Take Five Audio, click HERE for full details on our process.
