ViaBlue T6S RCA Plug Screw Type

ViaBlue T6S RCA Plug Screw Type
ViaBlue T6s RCA Plugs, Screw Type, 1 pr.
Our PriceCAD $33.49
CodeVB RCAPLGSRW
Weight Kg.065
In Stock
No Reviews
Save wishlist

ViaBlue™ T6s RCA plugs have contact pins made of bronze which are 24 carat gold-plated. The shells are made of aluminum. Two types are available, a solder and a screw version. The screw version can carry cables between 7-8 mm in diameter. PLEASE NOTE: The screw version is intended to be used with coaxial cable only.

For the assembly the stripped cable ends are screwed in the housing of the T6s solder RCA plug. The conductor is guided by the insulation to the pin and fixed by a screw. The shielding is pulled 360° around the cable,pushed into the housing and fixed by another screw. Finally, the two outer screws are tightened to fix the shell and hold the cable tight in the connector's housing. Cables with 7-8 mm diameter can be installed.

Technical specifications:
  • Max outer diameter: 13.5 mm
  • Contact: RCA norm
  • Finishing: 24 Karat Gold plated
  • Total length: 45.0 mm
  • Max cable input: for cables with Ø 7-8 mm
  • Marking: black / red
  • Screws: 1.5 mm Hexagon
  • Packing: 1 pair
